Pad And Pole Mount Photo Gallery

A generic image
500 kVA Pad Mounted Transformer
TX 4
3 Phase Transformer 500 kVA Pad Mounted Transformer Alternate

500 kVA Three Phase Pad Mounted Transformer
Primary Voltage: 12.47 kV, 13.2 kV, 34.5 kV
Secondary Voltage: 480/277 V
Models: CWS-500KVA3P-12.47-208 , CWS-500KVA3P-12.47-480 , CWS-500KVA3P-13.2K , CWS-500KVA3P-34.5K

100 kVA Transformer
100 kVA Open Top Transformer
100 kVA Loop Feed Transformer 100 kVA Data Sheet

100 kVA Loop Feed Pad Mounted Transformer
3 Phase, Wye Secondary
Primary Voltage: 12.47 kV
Secondary Voltage: 480/277 V
Model: CWS-500KVA3P-1247480

150 kVA Front View Transformer 150 kVA Side View Transformer 150 kVA Name Plate

150 kVA Three Phase Pad Mounted Transformer
Primary Voltage: 12.47 kV
Secondary Voltage: 120/240 V
Model: CWS-150KVA3P-12.47D

225 kVA Front View Transformer 225 kVA Side View Transformer 225 kVA Data Sheet

225 kVA Three Phase Pad Mounted Transformer
Primary Voltage: 480 V
Secondary Voltage: 120/240 V
Model: CWS-225KVA3P-0.480

Pole Mounted Transformer

30 to 300 kVA Single and Three Phase Pole Mounted Transformer
Primary Voltage: 14,400 V
Secondary Voltage: 208V/120, 480Y/277
Models: CWS-37-1PP-12.4-120, CWS-50-1PP-4.16, CWS-75-1PP-13.8-120, CWS-75-3PP-13.8-120

500 kVA Pole Mounted Transformer

500 kVA Single Phase Pole Mounted Transformer
Primary Voltage: 19.9 kV
Secondary Voltage: 120/240, 240/480, 277 V
Models: CWS-500-3PP-19.9-120, CWS-500-3PP-19.9-277

75 kVA Transformer 1
75 kVA Transformer 2
75 kVA Transformer Name Plate

75 kVA Single Phase Pole Mounted Transformer
Primary Voltage: 13.8 kV
Secondary Voltage: 120/240 V
Models: CWS-75-1PP-13.8-120, CWS-75-3PP-13.8-120


Part Number Inductance KVA Rating Frequency Phase High Voltage (HV) Low Voltage (LV) Qty. Price
CWS-75KVA1P-PM-13.8K-120 0 75 KVA 60 Hz 1 Phase 13,800 Volts 120/240 Volts In Stock: 0
$12,195.00
Buy Now
